Mark Levinson No. 536

Mark Levinson No. 536 - The power amplifier for any high-end system

A Mark Levinson No. 536 mono block power amplifier is developed based on the design of the legendary No. 33 and ML-2 amplifiers. The technical design and components have been improved, but the classic ML sound has been retained and refined. The amplifier runs with a very high bias current and thus in Class A mode under most listening conditions. It is only when you really push them that it switches to Class A/B.

No. The 536 is a Mono power amplifier that delivers 1 x 400W into 8 ohms, and it doubles the output all the way down to 2 ohms, where it delivers a whopping 1600 watts. No. The 536 is the perfect partner for any high-end loudspeaker.

Since 1972, Mark Levinson has been dedicated to a quest for the musical above all else. To achieve this goal, Mark Levinson engineers scoured the company's archives and ultimately developed a circuit design philosophy called Pure Path. In short, it's a discrete, direct-coupled, fully balanced, dual mono signal path that delivers unlimited dynamics with minimal noise. And it can be heard to that extent on No. 536.

Come by the store and listen to it or try it at home with our 30-day Buy & Try.

Specifications:

• Input connectors: One XLR Balanced, one RCA Unbalanced
• Speaker jacks: Two pairs of Hurricane speaker outputs
with banana plug (except on 230 VAC version)
• Control connector: Ethernet, RS-232, Trigger In, Trigger Out,
USB-A, Mini USB
• Rated output power: 400 W RMS @ 8 ohms, 800 W RMS @ 4
ohms, 20Hz to 20kHz at <0.3% THD, full output from 2.83VRMS
• Frequency response: 10Hz to 20kHz +/- 0.2dB
• Signal-to-noise ratio: >85dB, reference level 2.83 VRMS
• Input Impedance: 60k balanced; 30 k unbalanced
• Voltage gain: 26dB
• Input sensitivity: 2.83 VRMS output at 142mVRMS input
• Power requirements: 100V-, 120V-, 230V-; factory set for
country of destination, 1500W
• Dimensions (H x W x D): 7.65" x 17.75" x 19.83" (119.4 cm x
45.1 cm x 50.4 cm)
• Weight: Net weight 100 lbs (45.4 kg); Shipping Weight: 117 lbs
(53 kg)
